深溝ボールベアリング（開放型）
| 主要寸法 | 基本定格荷重 | 呼び番号 | 許容回転速度 | 参考質量 | |||||
| d | D | B | ｒ（最小） | Cｒ | C0ｒ | 開放形 | GR潤滑 | 油潤滑 | |
| 10.0 | 15.0 | 3.0 | 0.10 | 0.80 | 0.39 | 6700 | - | - | 0.002 |
| 10.0 | 19.0 | 5.0 | 0.30 | 1.60 | 0.75 | 6800 | 34000 | 40000 | 0.005 |
| 10.0 | 22.0 | 6.0 | 0.30 | 2.70 | 1.27 | 6900 | 32000 | 38000 | 0.011 |
| 10.0 | 26.0 | 8.0 | 0.30 | 4.58 | 1.97 | 6000 | 30000 | 36000 | 0.019 |
| 10.0 | 30.0 | 9.0 | 0.60 | 6.60 | 3.10 | 6200 | 24000 | 30000 | 0.031 |
| 10.0 | 35.0 | 11.0 | 0.60 | 8.06 | 3.40 | 6300 | 20000 | 26000 | 0.053 |
| 12.0 | 18.0 | 4.0 | 0.20 | 0.91 | 0.53 | 6701 | - | - | 0.003 |
| 12.0 | 21.0 | 5.0 | 0.30 | 1.92 | 1.04 | 6801 | 32000 | 38000 | 0.007 |
| 12.0 | 24.0 | 6.0 | 0.30 | 3.38 | 1.48 | 6901 | 30000 | 36000 | 0.013 |
| 12.0 | 28.0 | 8.0 | 0.30 | 4.98 | 2.39 | 6001 | 26000 | 32000 | 0.021 |
| 12.0 | 30.0 | 8.0 | 0.30 | 5.10 | 2.36 | 16001 | - | - | 0.019 |
| 12.0 | 32.0 | 10.0 | 0.60 | 6.89 | 3.10 | 6201 | 22000 | 28000 | 0.036 |
| 12.0 | 37.0 | 12.0 | 1.00 | 9.75 | 4.15 | 6301 | 19000 | 24000 | 0.058 |
| 15.0 | 21.0 | 4.0 | 0.20 | 0.85 | 0.49 | 6702 | - | - | 0.004 |
| 15.0 | 24.0 | 5.0 | 0.30 | 2.07 | 1.18 | 6802 | 28000 | 34000 | 0.008 |
| 15.0 | 28.0 | 7.0 | 0.30 | 4.00 | 2.02 | 6902 | 26000 | 30000 | 0.016 |
| 15.0 | 32.0 | 8.0 | 0.30 | 5.62 | 2.84 | 16002 | - | - | 0.028 |
| 15.0 | 32.0 | 9.0 | 0.30 | 5.48 | 2.80 | 6002 | 22000 | 28000 | 0.030 |
| 15.0 | 35.0 | 11.0 | 0.60 | 7.80 | 3.75 | 6202 | 19000 | 24000 | 0.043 |
| 15.0 | 42.0 | 13.0 | 1.00 | 11.40 | 5.40 | 6302 | 17000 | 20000 | 0.081 |
| 17.0 | 23.0 | 4.0 | 0.20 | 0.96 | 0.61 | 6703 | - | - | 0.004 |
| 17.0 | 26.0 | 5.0 | 0.30 | 2.18 | 1.28 | 6803 | 26000 | 30000 | 0.008 |
| 17.0 | 30.0 | 7.0 | 0.30 | 4.30 | 2.32 | 6903 | 24000 | 28000 | 0.018 |
| 17.0 | 35.0 | 8.0 | 0.30 | 6.50 | 3.36 | 16003 | 19000 | 24000 | 0.032 |
| 17.0 | 35.0 | 10.0 | 0.30 | 5.93 | 3.18 | 6003 | 19000 | 24000 | 0.038 |
| 17.0 | 40.0 | 12.0 | 0.60 | 9.56 | 4.75 | 6203 | 17000 | 20000 | 0.066 |
| 17.0 | 47.0 | 14.0 | 1.00 | 13.50 | 6.50 | 6303 | 15500 | 18000 | 0.110 |
| 17.0 | 62.0 | 17.0 | 1.10 | 21.80 | 9.85 | 6403 | 12000 | 15000 | 0.270 |
| 20.0 | 27.0 | 4.0 | 0.20 | 1.03 | 0.72 | 6704 | 22000 | 26000 | 0.006 |
| 20.0 | 32.0 | 7.0 | 0.30 | 3.45 | 2.25 | 6804 | 19000 | 22000 | 0.020 |
| 20.0 | 37.0 | 9.0 | 0.30 | 6.55 | 3.60 | 6904 | 17000 | 20000 | 0.036 |
| 20.0 | 42.0 | 8.0 | 0.30 | 7.90 | 4.45 | 16004 | 17000 | 20000 | 0.051 |
| 20.0 | 42.0 | 12.0 | 0.60 | 9.17 | 4.90 | 6004 | 15000 | 18000 | 0.069 |
| 20.0 | 47.0 | 14.0 | 1.00 | 12.70 | 6.50 | 6204 | 13000 | 16000 | 0.105 |
| 20.0 | 52.0 | 15.0 | 1.00 | 18.20 | 10.20 | 6304 | 10000 | 13000 | 0.144 |
| 20.0 | 72.0 | 19.0 | 1.00 | 31.10 | 15.20 | 6404 | - | - | 0.400 |
| 22.0 | 44.0 | 12.0 | 0.60 | 9.40 | 5.05 | 60/22 | 17000 | 20000 | 0.074 |
| 22.0 | 50.0 | 14.0 | 1.00 | 12.90 | 6.80 | 62/22 | 14000 | 16000 | 0.117 |
| 22.0 | 56.0 | 16.0 | 1.10 | 18.50 | 9.25 | 63/22 | 13000 | 16000 | 0.177 |
| 25.0 | 32.0 | 4.0 | 0.20 | 1.09 | 0.83 | 6705 | - | - | 0.007 |
| 25.0 | 37.0 | 7.0 | 0.30 | 3.70 | 2.65 | 6805 | 18000 | 22000 | 0.022 |
| 25.0 | 42.0 | 9.0 | 0.30 | 6.65 | 4.20 | 6905 | 16000 | 19000 | 0.042 |
| 25.0 | 47.0 | 8.0 | 0.30 | 8.84 | 5.63 | 16005 | 14000 | 17000 | 0.058 |
| 25.0 | 47.0 | 12.0 | 0.60 | 11.00 | 6.42 | 6005 | 15000 | 18000 | 0.079 |
| 25.0 | 52.0 | 15.0 | 1.00 | 15.10 | 8.90 | 6205 | 12000 | 15000 | 0.129 |
| 25.0 | 62.0 | 17.0 | 1.10 | 22.50 | 11.60 | 6305 | 11000 | 14000 | 0.220 |
| 25.0 | 80.0 | 21.0 | 1.50 | 37.20 | 18.80 | 6405 | 9000 | 11000 | 0.530 |
| 28.0 | 52.0 | 12.0 | 0.60 | 10.70 | 6.63 | 60/28 | 14000 | 16000 | 0.101 |
| 28.0 | 58.0 | 16.0 | 1.00 | 16.60 | 9.54 | 62/28 | 12000 | 14000 | 0.174 |
| 28.0 | 68.0 | 18.0 | 1.10 | 23.50 | 12.10 | 63/28 | 10000 | 12500 | 0.292 |
| 30.0 | 37.0 | 4.0 | 0.20 | 1.17 | 0.98 | 6706 | - | - | 0.008 |
| 30.0 | 42.0 | 7.0 | 0.30 | 4.04 | 3.14 | 6806 | 15000 | 18000 | 0.026 |
| 30.0 | 47.0 | 9.0 | 0.30 | 7.25 | 5.00 | 6906 | 14000 | 17000 | 0.049 |
| 30.0 | 55.0 | 9.0 | 0.30 | 11.20 | 7.36 | 16006 | 12000 | 15000 | 0.088 |
| 30.0 | 55.0 | 13.0 | 1.00 | 13.00 | 8.15 | 6006 | 12000 | 15000 | 0.113 |
| 30.0 | 62.0 | 16.0 | 1.00 | 19.50 | 11.20 | 6206 | 10000 | 13000 | 0.200 |
| 30.0 | 72.0 | 19.0 | 1.10 | 28.10 | 16.00 | 6306 | 9000 | 11000 | 0.349 |
| 30.0 | 90.0 | 23.0 | 1.50 | 44.60 | 23.00 | 6406 | 8300 | 10000 | 0.715 |
| 32.0 | 58.0 | 13.0 | 1.00 | 13.30 | 8.40 | 60/32 | 12000 | 14000 | 0.129 |
| 32.0 | 65.0 | 17.0 | 1.00 | 21.20 | 12.50 | 62/32 | 10000 | 12000 | 0.231 |
| 32.0 | 75.0 | 20.0 | 1.10 | 29.90 | 16.20 | 63/32 | 9000 | 11000 | 0.392 |
| 35.0 | 44.0 | 5.0 | 0.30 | 1.85 | 1.63 | 6707 | - | - | 0.015 |
| 35.0 | 47.0 | 7.0 | 0.30 | 4.27 | 3.59 | 6807 | 14000 | 16000 | 0.030 |
| 35.0 | 55.0 | 10.0 | 0.60 | 8.00 | 5.67 | 6907 | 12000 | 15000 | 0.086 |
| 35.0 | 62.0 | 9.0 | 0.30 | 12.50 | 9.50 | 16007 | 10000 | 13000 | 0.110 |
| 35.0 | 62.0 | 14.0 | 1.00 | 16.50 | 10.50 | 6007 | 10000 | 13000 | 0.149 |
| 35.0 | 72.0 | 17.0 | 1.10 | 25.50 | 15.30 | 6207 | 9000 | 11000 | 0.284 |
| 35.0 | 80.0 | 21.0 | 1.50 | 33.50 | 19.30 | 6307 | 8500 | 10000 | 0.462 |
| 35.0 | 100.0 | 25.0 | 1.50 | 55.30 | 31.00 | 6407 | 7000 | 8500 | 0.922 |
| 40.0 | 50.0 | 6.0 | 0.30 | 2.52 | 2.23 | 6708 | - | - | 0.023 |
| 40.0 | 52.0 | 7.0 | 0.30 | 6.35 | 5.55 | 6808 | 12000 | 14000 | 0.034 |
| 40.0 | 62.0 | 12.0 | 0.60 | 13.7 | 10.0 | 6908 | 11000 | 13000 | 0.112 |
| 40.0 | 68.0 | 9.0 | 0.60 | 13.5 | 10.0 | 16008 | 9500 | 12000 | 0.130 |
| 40.0 | 68.0 | 15.0 | 1.00 | 21.8 | 11.6 | 6008 | 9200 | 11600 | 0.185 |
| 40.0 | 80.0 | 18.0 | 1.10 | 30.1 | 18.6 | 6208 | 8200 | 9700 | 0.360 |
| 40.0 | 90.0 | 23.0 | 1.50 | 41.2 | 24.3 | 6308 | 7300 | 8700 | 0.609 |
| 40.0 | 110.0 | 27.0 | 2.00 | 67.8 | 36.4 | 6408 | 6500 | 7800 | 1.170 |
| 45.0 | 55.0 | 6.0 | 0.30 | 2.6 | 2.4 | 6709 | - | - | 0.025 |
| 45.0 | 58.0 | 7.0 | 0.30 | 6.6 | 6.2 | 6809 | 11000 | 13000 | 0.040 |
| 45.0 | 68.0 | 12.0 | 0.60 | 14.1 | 10.9 | 6909 | 9500 | 12000 | 0.126 |
| 45.0 | 75.0 | 10.0 | 0.60 | 15.4 | 12.2 | 16009 | 9000 | 11000 | 0.167 |
| 45.0 | 75.0 | 16.0 | 1.00 | 21.0 | 14.9 | 6009 | 8300 | 10500 | 0.236 |
| 45.0 | 85.0 | 19.0 | 1.10 | 33.2 | 21.0 | 6209 | 7500 | 8700 | 0.408 |
| 45.0 | 100.0 | 25.0 | 1.50 | 52.7 | 30.5 | 6309 | 6500 | 7800 | 0.839 |
| 45.0 | 120.0 | 29.0 | 2.00 | 78.4 | 46.3 | 6409 | 5800 | 6800 | 1.570 |
| 50.0 | 62.0 | 6.0 | 0.30 | 2.7 | 2.6 | 6710 | - | - | 0.340 |
| 50.0 | 65.0 | 7.0 | 0.30 | 6.4 | 6.2 | 6810 | 9500 | 11000 | 0.057 |
| 50.0 | 72.0 | 12.0 | 0.60 | 14.5 | 11.7 | 6910 | 9000 | 11000 | 0.135 |
| 50.0 | 80.0 | 10.0 | 0.60 | 16.0 | 13.1 | 16010 | 8500 | 10000 | 0.182 |
| 50.0 | 80.0 | 16.0 | 1.00 | 22.0 | 16.2 | 6010 | 8000 | 9700 | 0.252 |
| 50.0 | 90.0 | 20.0 | 1.10 | 35.4 | 23.3 | 6210 | 6800 | 8200 | 0.463 |
| 50.0 | 110.0 | 27.0 | 2.00 | 61.8 | 37.9 | 6310 | 6100 | 7300 | 1.060 |
| 50.0 | 130.0 | 31.0 | 2.10 | 92.5 | 55.2 | 6410 | 5100 | 6100 | 1.870 |
| 55.0 | 68.0 | 7.0 | 0.30 | 2.9 | 3.1 | 6711 | - | - | 0.550 |
| 55.0 | 72.0 | 9.0 | 0.30 | 9.1 | 8.5 | 6811 | 8500 | 10000 | 0.081 |
| 55.0 | 80.0 | 13.0 | 1.00 | 18.9 | 15.1 | 6911 | 8000 | 9500 | 0.180 |
| 55.0 | 90.0 | 11.0 | 0.60 | 19.1 | 16.2 | 16011 | 7500 | 9000 | 0.267 |
| 55.0 | 90.0 | 18.0 | 1.10 | 31.9 | 22.0 | 6011 | 6800 | 8700 | 0.365 |
| 55.0 | 100.0 | 21.0 | 1.50 | 43.3 | 28.1 | 6211 | 6100 | 7300 | 0.605 |
| 55.0 | 120.0 | 29.0 | 2.00 | 71.5 | 44.6 | 6311 | 5400 | 6500 | 1.340 |
| 55.0 | 140.0 | 33.0 | 2.10 | 101.0 | 62.4 | 6411 | 4800 | 5800 | 2.340 |
| 60.0 | 78.0 | 10.0 | 0.30 | 10.3 | 10.0 | 6812 | 7500 | 9000 | 0.101 |
| 60.0 | 85.0 | 13.0 | 1.00 | 19.4 | 16.2 | 6912 | 7500 | 9000 | 0.193 |
| 60.0 | 95.0 | 11.0 | 0.60 | 19.5 | 17.5 | 16012 | 6700 | 8000 | 0.285 |
| 60.0 | 95.0 | 18.0 | 1.10 | 30.7 | 22.7 | 6012 | 6400 | 8100 | 0.385 |
| 60.0 | 110.0 | 22.0 | 1.50 | 53.1 | 33.8 | 6212 | 5400 | 6800 | 0.791 |
| 60.0 | 130.0 | 31.0 | 2.10 | 82.5 | 50.4 | 6312 | 4800 | 5800 | 1.700 |
| 60.0 | 150.0 | 35.0 | 2.10 | 109.8 | 70.3 | 6412 | 4600 | 5400 | 2.800 |
| 65.0 | 85.0 | 10.0 | 0.60 | 10.8 | 10.7 | 6813 | 7000 | 8400 | 0.127 |
| 65.0 | 90.0 | 13.0 | 1.00 | 19.9 | 17.5 | 6913 | 6700 | 8000 | 0.206 |
| 65.0 | 100.0 | 11.0 | 0.60 | 20.7 | 18.4 | 16013 | 6300 | 7500 | 0.305 |
| 65.0 | 100.0 | 18.0 | 1.10 | 32.1 | 24.9 | 6013 | 6000 | 7600 | 0.411 |
| 65.0 | 120.0 | 23.0 | 1.50 | 56.2 | 41.3 | 6213 | 5100 | 6100 | 0.989 |
| 65.0 | 140.0 | 33.0 | 2.10 | 92.8 | 59.7 | 6313 | 4600 | 5400 | 2.080 |
| 65.0 | 160.0 | 37.0 | 2.10 | 119.0 | 78.0 | 6413 | 4400 | 5100 | 3.350 |
| 70.0 | 90.0 | 10.0 | 0.60 | 11.2 | 11.7 | 6814 | 6700 | 8000 | 0.135 |
| 70.0 | 100.0 | 16.0 | 1.00 | 23.7 | 21.1 | 6914 | 6300 | 7500 | 0.342 |
| 70.0 | 110.0 | 13.0 | 0.60 | 24.3 | 22.5 | 16014 | 6000 | 7000 | 0.447 |
| 70.0 | 110.0 | 20.0 | 1.10 | 38.6 | 30.6 | 6014 | 5500 | 6900 | 0.577 |
| 70.0 | 125.0 | 24.0 | 1.50 | 60.8 | 46.5 | 6214 | 4800 | 5800 | 1.080 |
| 70.0 | 150.0 | 35.0 | 2.10 | 105.0 | 69.0 | 6314 | 4400 | 5100 | 2.550 |
| 70.0 | 180.0 | 42.0 | 3.00 | 143.0 | 103.0 | 6414 | 3700 | 4400 | 4.640 |
| 75.0 | 95.0 | 10.0 | 0.60 | 11.3 | 11.9 | 6815 | 6300 | 7500 | 0.143 |
| 75.0 | 105.0 | 16.0 | 1.00 | 23.4 | 22.5 | 6915 | 6000 | 7000 | 0.365 |
| 75.0 | 115.0 | 13.0 | 0.60 | 25.0 | 23.9 | 16015 | 5600 | 6700 | 0.474 |
| 75.0 | 115.0 | 20.0 | 1.10 | 37.7 | 33.1 | 6015 | 5200 | 6500 | 0.604 |
| 75.0 | 130.0 | 25.0 | 1.50 | 66.5 | 50.5 | 6215 | 4600 | 5400 | 1.220 |
| 75.0 | 160.0 | 37.0 | 2.10 | 114.0 | 117.0 | 6315 | 4200 | 4800 | 3.010 |
| 75.0 | 190.0 | 45.0 | 3.00 | 153.0 | 114.0 | 6415 | 3500 | 4200 | 5.690 |
| 80.0 | 100.0 | 10.0 | 0.60 | 11.6 | 12.7 | 6816 | 6000 | 7000 | 0.152 |
| 80.0 | 110.0 | 16.0 | 1.00 | 25.0 | 23.9 | 6916 | 5600 | 6700 | 0.385 |
| 80.0 | 125.0 | 14.0 | 0.60 | 31.9 | 29.7 | 16016 | 5300 | 6300 | 0.608 |
| 80.0 | 125.0 | 22.0 | 1.10 | 47.5 | 39.8 | 6016 | 4770 | 6000 | 0.816 |
| 80.0 | 140.0 | 26.0 | 2.00 | 72.7 | 55.0 | 6216 | 4400 | 5100 | 1.400 |
| 80.0 | 170.0 | 39.0 | 2.10 | 120.0 | 87.0 | 6316 | 3700 | 4400 | 3.670 |
| 80.0 | 200.0 | 48.0 | 3.00 | 164.0 | 126.0 | 6416 | 3300 | 3900 | 7.000 |
| 85.0 | 110.0 | 13.0 | 1.00 | 16.0 | 16.8 | 6817 | 5300 | 6300 | 0.268 |
| 85.0 | 120.0 | 18.0 | 1.10 | 31.9 | 29.5 | 6917 | 5300 | 6300 | 0.525 |
| 85.0 | 130.0 | 14.0 | 0.60 | 32.5 | 31.5 | 16017 | 5000 | 6000 | 0.640 |
| 85.0 | 130.0 | 22.0 | 1.10 | 50.3 | 41.2 | 6017 | 4800 | 5600 | 0.841 |
| 85.0 | 150.0 | 28.0 | 2.00 | 83.2 | 64.0 | 6217 | 4200 | 4800 | 1.930 |
| 85.0 | 180.0 | 41.0 | 3.00 | 133.0 | 96.5 | 6317 | 3500 | 4200 | 4.210 |
| 85.0 | 210.0 | 52.0 | 4.00 | 169.0 | 137.0 | 6417 | 3100 | 3700 | 7.910 |
| 90.0 | 115.0 | 13.0 | 1.00 | 16.5 | 18.0 | 6818 | 5300 | 6300 | 0.282 |
| 90.0 | 125.0 | 18.0 | 1.10 | 32.8 | 31.5 | 6918 | 5000 | 6000 | 0.600 |
| 90.0 | 140.0 | 16.0 | 1.00 | 41.5 | 39.2 | 16018 | 4800 | 5600 | 0.845 |
| 90.0 | 140.0 | 24.0 | 1.50 | 58.5 | 50.0 | 6018 | 4600 | 5600 | 1.120 |
| 90.0 | 160.0 | 30.0 | 2.00 | 96.0 | 72.0 | 6218 | 3700 | 4400 | 2.130 |
| 90.0 | 190.0 | 43.0 | 3.00 | 144.0 | 109.0 | 6318 | 3300 | 3900 | 4.930 |
| 90.0 | 225.0 | 54.0 | 4.00 | 194.0 | 159.0 | 6418 | 2900 | 3500 | 10.100 |
| 95.0 | 120.0 | 13.0 | 1.00 | 18.6 | 19.8 | 6819 | 5000 | 6000 | 0.295 |
| 95.0 | 130.0 | 18.0 | 1.10 | 33.7 | 33.5 | 6919 | 4800 | 5600 | 0.588 |
| 95.0 | 145.0 | 16.0 | 1.00 | 43.0 | 42.0 | 16019 | 4500 | 5300 | 0.884 |
| 95.0 | 145.0 | 24.0 | 1.50 | 78.5 | 50.1 | 6019 | 4200 | 4800 | 1.160 |
| 95.0 | 170.0 | 32.0 | 2.10 | 109.0 | 79.1 | 6219 | 3500 | 4200 | 2.620 |
| 95.0 | 200.0 | 45.0 | 3.00 | 152.0 | 121.0 | 6319 | 3100 | 3700 | 5.660 |
| 95.0 | 240.0 | 55.0 | 4.00 | 203.0 | 170.0 | 6419 | 3000 | 3500 | 13.400 |
| 100.0 | 125.0 | 13.0 | 1.00 | 16.9 | 19.1 | 6820 | 4800 | 5600 | 0.310 |
| 100.0 | 140.0 | 20.0 | 1.10 | 44.5 | 42.0 | 6920 | 4500 | 5300 | 0.786 |
| 100.0 | 150.0 | 16.0 | 1.00 | 46.3 | 44.8 | 16020 | 4300 | 5000 | 0.915 |
| 100.0 | 150.0 | 24.0 | 1.10 | 63.5 | 55.4 | 6020 | 4000 | 4800 | 1.200 |
| 100.0 | 180.0 | 34.0 | 2.10 | 123.0 | 94.0 | 6220 | 3200 | 3800 | 3.230 |
| 100.0 | 215.0 | 47.0 | 3.00 | 173.0 | 141.0 | 6320 | 2800 | 3400 | 7.110 |
| 100.0 | 250.0 | 58.0 | 4.00 | 223.0 | 195.0 | 6420 | 2600 | 3200 | 12.800 |
| 105.0 | 130.0 | 13.0 | 1.00 | 17.4 | 20.4 | 6821 | 4500 | 5300 | 0.323 |
| 105.0 | 145.0 | 20.0 | 1.10 | 46.3 | 44.8 | 6921 | 4300 | 5000 | 0.805 |
| 105.0 | 160.0 | 18.0 | 1.00 | 52.0 | 51.0 | 16021 | 4000 | 4800 | 1.200 |
| 105.0 | 160.0 | 26.0 | 2.00 | 69.8 | 61.2 | 6021 | 4000 | 4800 | 1.560 |
| 105.0 | 190.0 | 36.0 | 2.10 | 133.0 | 104.0 | 6221 | 3000 | 3600 | 3.890 |
| 105.0 | 225.0 | 49.0 | 3.00 | 240.0 | 153.0 | 6321 | 2700 | 3200 | 8.030 |
| 110.0 | 140.0 | 16.0 | 1.00 | 24.3 | 27.2 | 6822 | 4300 | 5000 | 0.500 |
| 110.0 | 150.0 | 20.0 | 1.10 | 47.6 | 47.5 | 6922 | 4000 | 4800 | 0.840 |
| 110.0 | 170.0 | 19.0 | 1.00 | 57.2 | 57.0 | 16022 | 3800 | 4500 | 1.450 |
| 110.0 | 170.0 | 28.0 | 2.00 | 81.9 | 72.9 | 6022 | 3400 | 4200 | 1.890 |
| 110.0 | 200.0 | 38.0 | 2.10 | 136.0 | 112.0 | 6222 | 2800 | 3400 | 4.450 |
| 110.0 | 240.0 | 50.0 | 3.00 | 208.0 | 177.0 | 6322 | 2500 | 3000 | 9.670 |
| 120.0 | 150.0 | 16.0 | 1.00 | 25.0 | 26.0 | 6824 | 3800 | 4500 | 0.540 |
| 120.0 | 165.0 | 22.0 | 1.10 | 57.2 | 56.9 | 6924 | 3600 | 4300 | 1.150 |
| 120.0 | 180.0 | 19.0 | 1.00 | 60.5 | 64.0 | 16024 | 3400 | 4000 | 1.600 |
| 120.0 | 180.0 | 28.0 | 2.00 | 88.1 | 79.7 | 6024 | 3100 | 4000 | 1.990 |
| 120.0 | 215.0 | 40.0 | 2.10 | 157.0 | 132.0 | 6224 | 2700 | 3200 | 5.200 |
| 120.0 | 260.0 | 55.0 | 3.00 | 228.0 | 207.0 | 6324 | 2300 | 2800 | 12.200 |
| 130.0 | 165.0 | 18.0 | 1.10 | 32.5 | 34.0 | 6826 | 3600 | 4300 | 0.774 |
| 130.0 | 180.0 | 24.0 | 1.50 | 69.5 | 70.0 | 6926 | 3400 | 4000 | 1.920 |
| 130.0 | 200.0 | 22.0 | 1.10 | 78.5 | 81.5 | 16026 | 3200 | 3800 | 2.420 |
| 130.0 | 200.0 | 33.0 | 2.00 | 102.0 | 93.9 | 6026 | 3000 | 3600 | 3.150 |
| 130.0 | 230.0 | 40.0 | 3.00 | 166.0 | 148.0 | 6226 | 2500 | 3000 | 6.190 |
| 130.0 | 280.0 | 58.0 | 4.00 | 250.0 | 240.0 | 6326 | 2100 | 2700 | 12.700 |
| 140.0 | 175.0 | 18.0 | 1.10 | 34.0 | 36.5 | 6828 | 3400 | 4000 | 0.828 |
| 140.0 | 190.0 | 24.0 | 1.50 | 71.2 | 74.6 | 6928 | 3200 | 3800 | 1.600 |
| 140.0 | 210.0 | 22.0 | 1.10 | 78.6 | 84.5 | 16028 | 3000 | 3600 | 3.080 |
| 140.0 | 210.0 | 33.0 | 2.00 | 116.0 | 109.0 | 6028 | 2800 | 3600 | 3.190 |
| 140.0 | 250.0 | 42.0 | 3.00 | 167.0 | 151.0 | 6228 | 2300 | 2800 | 7.770 |
| 140.0 | 300.0 | 62.0 | 4.00 | 254.0 | 246.0 | 6328 | 1900 | 2500 | 22.700 |
| 140.0 | 160.0 | 20.0 | 1.10 | 42.5 | 44.0 | 6830 | 3000 | 3600 | 1.120 |
| 150.0 | 210.0 | 28.0 | 2.00 | 88.6 | 93.0 | 6930 | 2800 | 3400 | 3.050 |
| 150.0 | 225.0 | 24.0 | 1.10 | 92.3 | 98.0 | 16030 | 2600 | 3200 | 3.150 |
| 150.0 | 225.0 | 35.0 | 2.10 | 125.0 | 124.0 | 6030 | 2600 | 3200 | 4.800 |
| 150.0 | 270.0 | 45.0 | 3.00 | 190.0 | 183.0 | 6230 | 1900 | 2500 | 10.400 |
| 150.0 | 320.0 | 65.0 | 4.00 | 278.0 | 280.0 | 6330 | 1800 | 2300 | 21.700 |
| 160.0 | 200.0 | 20.0 | 1.10 | 44.0 | 48.0 | 6832 | 2800 | 3400 | 1.2 |
| 160.0 | 220.0 | 28.0 | 2.00 | 92.3 | 98.0 | 6932 | 2600 | 3200 | 3.3 |
| 160.0 | 240.0 | 25.0 | 1.50 | 99.0 | 108.0 | 16032 | 2400 | 3000 | 3.7 |
| 160.0 | 240.0 | 38.0 | 2.10 | 138.0 | 137.0 | 6032 | 2400 | 3000 | 5.9 |
| 160.0 | 290.0 | 48.0 | 3.00 | 215.0 | 218.0 | 6232 | 1800 | 2300 | 12.2 |
| 160.0 | 340.0 | 68.0 | 4.00 | 312.0 | 325.0 | 6332 | 1700 | 2100 | 26.3 |
| 170.0 | 215.0 | 22.0 | 1.10 | 54.0 | 58.5 | 6834 | 2600 | 3200 | 1.6 |
| 170.0 | 230.0 | 28.0 | 2.00 | 93.6 | 106.0 | 6934 | 2400 | 3000 | 3.4 |
| 170.0 | 260.0 | 28.0 | 1.50 | 118.0 | 129.0 | 16034 | 2200 | 2800 | 5.0 |
| 170.0 | 260.0 | 42.0 | 2.10 | 161.0 | 160.0 | 6034 | 2100 | 2700 | 8.1 |
| 170.0 | 310.0 | 52.0 | 4.00 | 210.0 | 213.0 | 6234 | 1900 | 2400 | 15.2 |
| 170.0 | 360.0 | 72.0 | 4.00 | 303.0 | 330.0 | 6334 | 1700 | 2000 | 31.1 |
| 180.0 | 225.0 | 22.0 | 1.10 | 56.0 | 63.0 | 6836 | 2400 | 3000 | 1.7 |
| 180.0 | 250.0 | 33.0 | 2.00 | 119.0 | 123.0 | 6936 | 2200 | 2800 | 5.1 |
| 180.0 | 280.0 | 31.0 | 2.00 | 138.0 | 146.0 | 16036 | 2000 | 2600 | 6.6 |
| 180.0 | 280.0 | 46.0 | 2.10 | 196.0 | 203.0 | 6036 | 2000 | 2600 | 8.6 |
| 180.0 | 320.0 | 52.0 | 4.00 | 257.0 | 280.0 | 6236 | 1800 | 2200 | 19.4 |
| 180.0 | 380.0 | 75.0 | 4.00 | 340.0 | 393.0 | 6336 | 1600 | 2000 | 42.5 |
| 190.0 | 240.0 | 24.0 | 1.50 | 67.0 | 73.5 | 6838 | 2200 | 2800 | 2.1 |
| 190.0 | 260.0 | 33.0 | 2.00 | 117.0 | 134.0 | 6938 | 2200 | 2800 | 5.3 |
| 190.0 | 290.0 | 31.0 | 2.00 | 148.0 | 166.0 | 16038 | 2000 | 2600 | 7.9 |
| 190.0 | 290.0 | 46.0 | 2.10 | 185.0 | 200.0 | 6038 | 2000 | 2600 | 11.0 |
| 190.0 | 340.0 | 55.0 | 4.00 | 255.0 | 280.0 | 6238 | 1700 | 2000 | 23.0 |
| 190.0 | 400.0 | 78.0 | 5.00 | 371.0 | 420.0 | 6338 | 1600 | 1900 | 49.0 |
| 200.0 | 250.0 | 24.0 | 1.50 | 76.1 | 102.0 | 6840 | 2200 | 2800 | 2.7 |
| 200.0 | 280.0 | 38.0 | 2.10 | 148.0 | 160.0 | 6940 | 2000 | 2600 | 7.4 |
| 200.0 | 310.0 | 34.0 | 2.00 | 160.0 | 180.0 | 16040 | 1900 | 2400 | 8.9 |
| 200.0 | 310.0 | 51.0 | 2.10 | 223.0 | 246.0 | 6040 | 1900 | 2400 | 11.7 |
| 200.0 | 360.0 | 58.0 | 4.00 | 289.0 | 336.0 | 6240 | 1700 | 2000 | 22.5 |
| 200.0 | 420.0 | 80.0 | 5.00 | 370.0 | 460.0 | 6340 | 1500 | 1800 | 59.2 |
| 220.0 | 270.0 | 24.0 | 1.50 | 78.0 | 110.0 | 6844 | 1900 | 2400 | 3.0 |
| 220.0 | 300.0 | 38.0 | 2.10 | 155.0 | 180.0 | 6944 | 1900 | 2400 | 8.0 |
| 220.0 | 340.0 | 37.0 | 2.10 | 174.0 | 204.0 | 16044 | 1800 | 2200 | 11.5 |
| 220.0 | 340.0 | 56.0 | 3.00 | 251.0 | 292.0 | 6044 | 1800 | 2000 | 19.4 |
| 220.0 | 400.0 | 65.0 | 4.00 | 298.0 | 365.0 | 6244 | 1500 | 1800 | 36.5 |
| 220.0 | 460.0 | 88.0 | 5.00 | 407.0 | 522.0 | 6344 | 1300 | 1600 | 74.6 |
| 240.0 | 300.0 | 28.0 | 2.00 | 108.0 | 145.0 | 6848 | 1800 | 2200 | 4.5 |
| 240.0 | 320.0 | 38.0 | 2.10 | 159.0 | 200.0 | 6948 | 1800 | 2200 | 8.6 |
| 240.0 | 360.0 | 37.0 | 2.10 | 178.0 | 220.0 | 16048 | 1700 | 2000 | 14.5 |
| 240.0 | 360.0 | 56.0 | 3.00 | 256.0 | 316.0 | 6048 | 1700 | 2000 | 20.4 |
| 240.0 | 440.0 | 72.0 | 4.00 | 362.0 | 472.0 | 6248 | 1300 | 1600 | 53.9 |
| 260.0 | 320.0 | 28.0 | 2.00 | 111.0 | 153.0 | 6852 | 1700 | 2000 | 4.8 |
| 260.0 | 360.0 | 46.0 | 2.10 | 212.0 | 265.0 | 6952 | 1600 | 1900 | 14.5 |
| 260.0 | 400.0 | 44.0 | 3.00 | 235.0 | 310.0 | 16052 | 1500 | 1800 | 21.5 |
| 260.0 | 400.0 | 65.0 | 4.00 | 291.0 | 375.0 | 6052 | 1500 | 1800 | 29.5 |
| 280.0 | 350.0 | 33.0 | 2.00 | 138.0 | 195.0 | 6856 | 1600 | 1900 | 7.4 |
| 280.0 | 380.0 | 46.0 | 2.10 | 216.0 | 285.0 | 6956 | 1500 | 1800 | 15.5 |
| 280.0 | 420.0 | 65.0 | 4.00 | 305.0 | 405.0 | 6056 | 1400 | 1700 | 32.2 |
| 300.0 | 380.0 | 38.0 | 2.10 | 172.0 | 245.0 | 6860 | 1400 | 1700 | 10.5 |
| 300.0 | 420.0 | 56.0 | 3.00 | 268.0 | 370.0 | 6960 | 1300 | 1600 | 26.7 |
| 300.0 | 460.0 | 74.0 | 4.00 | 356.0 | 500.0 | 6060 | 1200 | 1500 | 45.3 |
| 320.0 | 400.0 | 38.0 | 2.10 | 172.0 | 240.0 | 6864 | 1300 | 1600 | 11.0 |
| 320.0 | 440.0 | 56.0 | 3.00 | 265.0 | 370.0 | 6964 | 1300 | 1600 | 24.9 |
| 320.0 | 480.0 | 74.0 | 4.00 | 360.0 | 524.0 | 6064 | 1100 | 1400 | 48.4 |
| 340.0 | 460.0 | 56.0 | 3.00 | 272.0 | 410.0 | 6968 | 1000 | 1300 | 27.0 |
| 360.0 | 440.0 | 38.0 | 2.10 | 126.0 | 242.0 | 6872 | 1100 | 1400 | 12.2 |
| 360.0 | 540.0 | 82.0 | 5.00 | 449.0 | 713.0 | 6072 | 1000 | 1300 | 71.6 |
| 380.0 | 480.0 | 46.0 | 2.10 | 214.0 | 314.0 | 6876 | 1000 | 1300 | 20.5 |
| 400.0 | 500.0 | 46.0 | 3.50 | 235.0 | 385.0 | 6880 | 950 | 1200 | 22.0 |
| 400.0 | 540.0 | 65.0 | 4.00 | 283.0 | 582.0 | 6980 | 950 | 1200 | 39.5 |
| 400.0 | 600.0 | 90.0 | 6.00 | 505.0 | 852.0 | 6080 | 900 | 1100 | 107.0 |
| 420.0 | 560.0 | 65.0 | 4.00 | 285.0 | 595.0 | 6984 | 900 | 1100 | 42.0 |
| 440.0 | 540.0 | 46.0 | 3.50 | 247.0 | 427.0 | 6888 | 900 | 1100 | 23.6 |
| 440.0 | 600.0 | 74.0 | 4.00 | 292.0 | 648.0 | 6988 | 900 | 1100 | 60.5 |
| 440.0 | 650.0 | 94.0 | 6.00 | 536.0 | 936.0 | 6088 | 850 | 1000 | 107.0 |
| 460.0 | 580.0 | 56.0 | 3.00 | 310.0 | 561.0 | 6892 | 900 | 1100 | 33.5 |
| 460.0 | 620.0 | 74.0 | 4.00 | 410.0 | 728.0 | 6992 | 850 | 1000 | 65.5 |
| 460.0 | 680.0 | 100.0 | 6.00 | 605.0 | 1080.0 | 6092 | 800 | 950 | 130.0 |
| 480.0 | 700.0 | 100.0 | 6.00 | 611.0 | 1120.0 | 6096 | 750 | 900 | 138.0 |
| 500.0 | 620.0 | 56.0 | 3.00 | 327.0 | 611.0 | 68/500 | 800 | 950 | 36.0 |
| 500.0 | 670.0 | 78.0 | 5.00 | 457.0 | 852.0 | 69/500 | 750 | 900 | 80.0 |
| 500.0 | 720.0 | 0.0 | 6.00 | 630.0 | 1170.0 | 60/500 | 750 | 900 | 135.0 |
| 530.0 | 650.0 | 56.0 | 3.00 | 317.0 | 643.0 | 68/530 | 750 | 850 | 40.0 |
| 530.0 | 710.0 | 82.0 | 5.00 | 475.0 | 912.0 | 69/530 | 700 | 850 | 92.0 |
| 530.0 | 780.0 | 12.0 | 6.00 | 680.0 | 1300.0 | 60/530 | 670 | 800 | 185.0 |
| 560.0 | 750.0 | 85.0 | 5.00 | 525.0 | 1040.0 | 69/560 | 670 | 800 | 111.0 |
| 600 | 730 | 60 | 3.00 | 357 | 759 | 68/600 | 670 | 800 | 53.5 |
| 630 | 850 | 100 | 6.00 | 635 | 1320 | 69/630 | 600 | 700 | 165 |
| 630 | 920 | 128 | 7.50 | 819 | 1760 | 60/630 | 560 | 670 | 295 |
| 670 | 820 | 69 | 4.00 | 420 | 980 | 68/670 | 560 | 670 | 82 |
| 710 | 1030 | 140 | 7.50 | 956 | 2200 | 60/710 | 480 | 560 | 395 |
| 800 | 1150 | 155 | 7.50 | 1470 | 2230 | 60/800 | 150 | 530 | 550 |
| 850 | 1030 | 82 | 5.00 | 428 | 1303 | 68/850 | 150 | 530 | 144 |
| 900 | 1090 | 85 | 5.00 | 607 | 1580 | 68/900 | 380 | 450 | 164 |
| 1000 | 1220 | 100 | 6.00 | 636 | 1780 | 68/1000 | 340 | 400 | 266 |
| 1180 | 1420 | 106 | 6.00 | 1170 | 3230 | 68/1180 | 260 | 320 | 330 |
深溝ボールベアリング（密封型）
| 主要寸法 | 基本定格荷重（Z） | 呼び番号 | 許容回転速度（Z） | 参考質量（Z） | ||||||||
| d | D | B | ｒ（最小） | Cｒ | C0ｒ | 片シールド形 | 両シールド形 | シール形 | グリース潤滑（Z・ZZ） | グリース潤滑（2RS） | 油潤滑 | |
| 10.0 | 15.0 | 3.0 | 0.10 | 0.80 | 0.39 | 6700Z | ZZ | 2RS | - | - | - | 0.002 |
| 10.0 | 19.0 | 5.0 | 0.30 | 1.83 | 0.92 | 6800Z | ZZ | 2RS | 36000 | 20000 | 42000 | 0.005 |
| 10.0 | 22.0 | 6.0 | 0.30 | 1.95 | 0.75 | 6900Z | ZZ | 2RS | 32000 | 19000 | 40000 | 0.010 |
| 10.0 | 26.0 | 8.0 | 0.30 | 4.55 | 1.97 | 6000Z | ZZ | 2RS | 30000 | 19000 | 36000 | 0.020 |
| 10.0 | 30.0 | 9.0 | 0.60 | 6.60 | 3.20 | 6200Z | ZZ | 2RS | 24000 | 17000 | 30000 | 0.030 |
| 10.0 | 35.0 | 11.0 | 0.60 | 8.06 | 3.40 | 6300Z | ZZ | 2RS | 20000 | 15000 | 26000 | 0.049 |
| 12.0 | 18.0 | 4.0 | 0.20 | 0.91 | 0.53 | 6701Z | ZZ | 2RS | - | - | - | 0.003 |
| 12.0 | 21.0 | 5.0 | 0.30 | 1.91 | 1.04 | 6801Z | ZZ | 2RS | 32000 | 19000 | 38000 | 0.006 |
| 12.0 | 24.0 | 6.0 | 0.30 | 2.25 | 0.98 | 6901Z | ZZ | 2RS | 30000 | 18000 | 36000 | 0.011 |
| 12.0 | 28.0 | 8.0 | 0.30 | 4.98 | 2.39 | 6001Z | ZZ | 2RS | 26000 | 17000 | 32000 | 0.019 |
| 12.0 | 32.0 | 10.0 | 0.60 | 6.89 | 3.10 | 6201Z | ZZ | 2RS | 22000 | 15000 | 28000 | 0.034 |
| 12.0 | 37.0 | 12.0 | 1.00 | 9.75 | 4.15 | 6301Z | ZZ | 2RS | 19000 | 14000 | 24000 | 0.057 |
| 15.0 | 21.0 | 4.0 | 0.20 | 0.85 | 0.49 | 3701Z | ZZ | 2RS | - | - | - | 0.004 |
| 15.0 | 24.0 | 5.0 | 0.30 | 2.07 | 1.26 | 6802Z | ZZ | 2RS | 28000 | 17000 | 34000 | 0.007 |
| 15.0 | 28.0 | 7.0 | 0.30 | 4.33 | 2.25 | 6902Z | ZZ | 2RS | 24000 | 16000 | 29000 | 0.015 |
| 15.0 | 32.0 | 9.0 | 0.30 | 5.48 | 2.80 | 6002Z | ZZ | 2RS | 22000 | 14000 | 28000 | 0.029 |
| 15.0 | 35.0 | 11.0 | 0.60 | 7.80 | 3.75 | 6202Z | ZZ | 2RS | 19000 | 13000 | 24000 | 0.040 |
| 15.0 | 42.0 | 13.0 | 1.00 | 11.40 | 5.40 | 6302Z | ZZ | 2RS | 17000 | 12000 | 20000 | 0.080 |
| 17.0 | 23.0 | 4.0 | 0.20 | 0.96 | 0.61 | 6702Z | ZZ | 2RS | - | - | - | 0.004 |
| 17.0 | 26.0 | 5.0 | 0.30 | 2.22 | 1.46 | 6803Z | ZZ | 2RS | 24000 | 16000 | 30000 | 0.008 |
| 17.0 | 30.0 | 7.0 | 0.30 | 4.60 | 2.55 | 6903Z | ZZ | 2RS | 22000 | 14000 | 28000 | 0.018 |
| 17.0 | 35.0 | 10.0 | 0.30 | 5.93 | 3.18 | 6003Z | ZZ | 2RS | 19000 | 13000 | 24000 | 0.037 |
| 17.0 | 40.0 | 12.0 | 0.60 | 9.56 | 4.75 | 6203Z | ZZ | 2RS | 17000 | 12000 | 20000 | 0.065 |
| 17.0 | 47.0 | 14.0 | 1.00 | 13.50 | 6.50 | 6303Z | ZZ | 2RS | 15500 | 11000 | 18000 | 0.011 |
| 20.0 | 27.0 | 4.0 | 0.20 | 1.03 | 0.72 | 6704Z | ZZ | 2RS | - | - | - | 0.006 |
| 20.0 | 32.0 | 7.0 | 0.30 | 3.45 | 2.25 | 6804Z | ZZ | 2RS | 19000 | 13000 | 24000 | 0.018 |
| 20.0 | 37.0 | 9.0 | 0.30 | 6.55 | 3.60 | 6904Z | ZZ | 2RS | 18000 | 12000 | 22000 | 0.037 |
| 20.0 | 42.0 | 12.0 | 0.60 | 9.17 | 4.90 | 6004Z | ZZ | 2RS | 17000 | 11000 | 20000 | 0.067 |
| 20.0 | 47.0 | 14.0 | 1.00 | 12.70 | 6.50 | 6204Z | ZZ | 2RS | 15000 | 10000 | 18000 | 0.103 |
| 20.0 | 52.0 | 15.0 | 1.00 | 15.90 | 7.80 | 6304Z | ZZ | 2RS | 13000 | 9500 | 16000 | 0.140 |
| 22.0 | 44.0 | 12.0 | 0.60 | 9.40 | 5.05 | 60/22Z | ZZ | 2RS | 17000 | 10000 | 20000 | 0.074 |
| 22.0 | 50.0 | 14.0 | 1.00 | 12.90 | 6.80 | 62/22Z | ZZ | 2RS | 14000 | 9700 | 16000 | 0.117 |
| 22.0 | 56.0 | 16.0 | 1.10 | 18.50 | 9.25 | 63/22Z | ZZ | 2RS | 13000 | 9200 | 16000 | 0.177 |
| 25.0 | 32.0 | 4.0 | 0.20 | 1.09 | 0.83 | 6705Z | ZZ | 2RS | - | - | - | 0.007 |
| 25.0 | 37.0 | 7.0 | 0.30 | 3.70 | 2.65 | 6805Z | ZZ | 2RS | 17000 | 11000 | 20000 | 0.022 |
| 25.0 | 42.0 | 9.0 | 0.30 | 7.32 | 4.56 | 6905Z | ZZ | 2RS | 16000 | 10000 | 19000 | 0.043 |
| 25.0 | 47.0 | 12.0 | 0.60 | 11.00 | 6.42 | 6005Z | ZZ | 2RS | 15000 | 9500 | 18000 | 0.077 |
| 25.0 | 52.0 | 15.0 | 1.00 | 15.10 | 8.90 | 6205Z | ZZ | 2RS | 12000 | 8500 | 15000 | 0.127 |
| 25.0 | 62.0 | 17.0 | 1.10 | 22.50 | 11.60 | 6305Z | ZZ | 2RS | 11000 | 7500 | 14000 | 0.219 |
| 28.0 | 52.0 | 12.0 | 0.60 | 10.70 | 6.63 | 60/28Z | ZZ | 2RS | 14000 | 8400 | 16000 | 0.101 |
| 28.0 | 58.0 | 16.0 | 1.00 | 16.60 | 9.54 | 62/28Z | ZZ | 2RS | 12000 | 8100 | 14000 | 0.174 |
| 28.0 | 68.0 | 18.0 | 1.10 | 23.50 | 12.10 | 63/28Z | ZZ | 2RS | 10000 | 7400 | 12500 | 0.292 |
| 30.0 | 37.0 | 4.0 | 0.20 | 1.17 | 0.98 | 6706Z | ZZ | 2RS | - | - | - | 0.008 |
| 30.0 | 42.0 | 7.0 | 0.30 | 4.15 | 3.32 | 6806Z | ZZ | 2RS | 15000 | 9500 | 18000 | 0.025 |
| 30.0 | 47.0 | 9.0 | 0.30 | 7.25 | 5.00 | 6906Z | ZZ | 2RS | 14000 | 8500 | 17000 | 0.049 |
| 30.0 | 55.0 | 13.0 | 1.00 | 13.50 | 8.15 | 6006Z | ZZ | 2RS | 12000 | 8000 | 15000 | 0.111 |
| 30.0 | 62.0 | 16.0 | 1.00 | 19.50 | 11.20 | 6206Z | ZZ | 2RS | 10000 | 7500 | 13000 | 0.197 |
| 30.0 | 72.0 | 19.0 | 1.10 | 28.10 | 16.00 | 6306Z | ZZ | 2RS | 9000 | 6300 | 11000 | 0.347 |
| 32.0 | 58.0 | 13.0 | 1.00 | 13.30 | 8.40 | 60/32Z | ZZ | 2RS | 12000 | 7200 | 14000 | 0.129 |
| 32.0 | 65.0 | 17.0 | 1.00 | 21.20 | 12.50 | 62/32Z | ZZ | 2RS | 10000 | 7100 | 12000 | 0.236 |
| 32.0 | 75.0 | 20.0 | 1.10 | 29.90 | 16.20 | 63/32Z | ZZ | 2RS | 90000 | 6500 | 11000 | 0.392 |
| 35.0 | 44.0 | 5.0 | 0.30 | 1.85 | 1.63 | 6707Z | ZZ | 2RS | - | - | - | 0.015 |
| 35.0 | 47.0 | 7.0 | 0.30 | 4.29 | 3.60 | 6807Z | ZZ | 2RS | 13000 | 8000 | 16000 | 0.029 |
| 35.0 | 55.0 | 10.0 | 0.60 | 9.54 | 6.83 | 6907Z | ZZ | 2RS | 11000 | 7500 | 14000 | 0.078 |
| 35.0 | 62.0 | 14.0 | 1.00 | 16.00 | 103.00 | 6007Z | ZZ | 2RS | 10000 | 7000 | 13000 | 0.150 |
| 35.0 | 72.0 | 17.0 | 1.10 | 25.50 | 15.30 | 6207Z | ZZ | 2RS | 9000 | 6300 | 11000 | 0.280 |
| 35.0 | 80.0 | 21.0 | 1.50 | 35.70 | 19.50 | 6307Z | ZZ | 2RS | 8500 | 6000 | 10000 | 0.465 |
| 40.0 | 50.0 | 6.0 | 0.30 | 2.52 | 2.23 | 6708Z | ZZ | 2RS | - | - | - | 0.023 |
| 40.0 | 52.0 | 7.0 | 0.30 | 4.52 | 4.10 | 6808Z | ZZ | 2RS | 11000 | 7500 | 14000 | 0.033 |
| 40.0 | 62.0 | 12.0 | 0.60 | 12.2 | 8.9 | 6908Z | ZZ | 2RS | 10000 | 6700 | 13000 | 0.115 |
| 40.0 | 68.0 | 15.0 | 1.00 | 16.8 | 11.7 | 6008Z | ZZ | 2RS | 9200 | 6300 | 11600 | 0.193 |
| 40.0 | 80.0 | 18.0 | 1.10 | 32.0 | 18.6 | 6208Z | ZZ | 2RS | 8200 | 5600 | 9700 | 0.345 |
| 40.0 | 90.0 | 23.0 | 1.50 | 41.5 | 24.3 | 6308Z | ZZ | 2RS | 7300 | 5000 | 8700 | 0.603 |
| 45.0 | 55.0 | 6.0 | 0.30 | 2.6 | 2.4 | 6709Z | ZZ | 2RS | - | - | - | 0.025 |
| 45.0 | 58.0 | 7.0 | 0.30 | 4.7 | 4.5 | 6809Z | ZZ | 2RS | 9500 | 6700 | 2000 | 0.041 |
| 45.0 | 68.0 | 12.0 | 0.60 | 14.0 | 10.9 | 6909Z | ZZ | 2RS | 9000 | 6000 | 1000 | 0.131 |
| 45.0 | 75.0 | 16.0 | 1.00 | 21.0 | 14.9 | 6009Z | ZZ | 2RS | 8300 | 5600 | 500 | 0.236 |
| 45.0 | 85.0 | 19.0 | 1.10 | 33.2 | 21.0 | 6209Z | ZZ | 2RS | 7500 | 5000 | 8700 | 0.397 |
| 45.0 | 100.0 | 25.0 | 1.50 | 52.7 | 30.5 | 6309Z | ZZ | 2RS | 6500 | 4500 | 7800 | 0.814 |
| 50.0 | 62.0 | 6.0 | 0.30 | 2.7 | 2.6 | 6710Z | ZZ | 2RS | - | - | - | 0.340 |
| 50.0 | 65.0 | 7.0 | 0.30 | 6.4 | 6.2 | 6810Z | ZZ | 2RS | 9000 | 6000 | 11000 | 0.057 |
| 50.0 | 72.0 | 12.0 | 0.60 | 14.4 | 11.7 | 6910Z | ZZ | 2RS | 8500 | 5600 | 10000 | 0.139 |
| 50.0 | 80.0 | 16.0 | 1.00 | 22.0 | 16.2 | 6010Z | ZZ | 2RS | 8000 | 5000 | 9700 | 0.263 |
| 50.0 | 90.0 | 20.0 | 1.10 | 35.4 | 23.3 | 6210Z | ZZ | 2RS | 6800 | 4800 | 8200 | 0.476 |
| 50.0 | 110.0 | 27.0 | 2.00 | 61.8 | 37.9 | 6310Z | ZZ | 2RS | 6100 | 4300 | 7300 | 1.050 |
| 55.0 | 68.0 | 7.0 | 0.30 | 2.9 | 3.1 | 6711Z | ZZ | 2RS | - | - | - | 0.550 |
| 55.0 | 72.0 | 9.0 | 0.30 | 9.1 | 8.5 | 6811Z | ZZ | 2RS | 8500 | 5300 | 10000 | 0.081 |
| 55.0 | 80.0 | 13.0 | 1.00 | 18.9 | 15.1 | 6911Z | ZZ | 2RS | 8000 | 5000 | 9500 | 0.180 |
| 55.0 | 90.0 | 18.0 | 1.10 | 26.7 | 20.1 | 6011Z | ZZ | 2RS | 7500 | 4500 | 9000 | 0.382 |
| 55.0 | 100.0 | 21.0 | 1.50 | 43.3 | 28.1 | 6211Z | ZZ | 2RS | 6100 | 4300 | 7300 | 0.621 |
| 55.0 | 120.0 | 29.0 | 2.00 | 71.5 | 44.6 | 6311Z | ZZ | 2RS | 5400 | 3800 | 6500 | 1.370 |
| 60.0 | 78.0 | 10.0 | 0.30 | 10.3 | 10.0 | 6812Z | ZZ | 2RS | 7500 | 4800 | 9000 | 0.101 |
| 60.0 | 85.0 | 13.0 | 1.00 | 19.4 | 16.2 | 6912Z | ZZ | 2RS | 7500 | 4500 | 9000 | 0.193 |
| 60.0 | 95.0 | 18.0 | 1.10 | 30.2 | 23.0 | 6012Z | ZZ | 2RS | 6700 | 4300 | 8000 | 0.399 |
| 60.0 | 110.0 | 22.0 | 1.50 | 53.3 | 33.5 | 6212Z | ZZ | 2RS | 5400 | 4000 | 6800 | 0.791 |
| 60.0 | 130.0 | 31.0 | 2.10 | 81.9 | 51.8 | 6312Z | ZZ | 2RS | 5100 | 3400 | 6000 | 1.710 |
| 65.0 | 85.0 | 10.0 | 0.60 | 10.8 | 10.7 | 6813Z | ZZ | 2RS | 7000 | 4500 | 8400 | 0.127 |
| 65.0 | 90.0 | 13.0 | 1.00 | 19.9 | 17.5 | 6913Z | ZZ | 2RS | 6700 | 4300 | 8000 | 0.206 |
| 65.0 | 100.0 | 18.0 | 1.10 | 32.1 | 24.9 | 6013Z | ZZ | 2RS | 6000 | 4000 | 7600 | 0.414 |
| 65.0 | 120.0 | 23.0 | 1.50 | 56.5 | 41.2 | 6213Z | ZZ | 2RS | 5100 | 3600 | 6100 | 0.986 |
| 65.0 | 140.0 | 33.0 | 2.10 | 92.5 | 59.6 | 6313Z | ZZ | 2RS | 4800 | 3200 | 5600 | 2.150 |
| 70.0 | 90.0 | 10.0 | 0.60 | 11.2 | 11.7 | 6814Z | ZZ | 2RS | 6700 | 4300 | 8000 | 0.135 |
| 70.0 | 100.0 | 16.0 | 1.00 | 23.7 | 21.1 | 1914Z | ZZ | 2RS | 6300 | 4000 | 7500 | 0.342 |
| 70.0 | 110.0 | 20.0 | 1.10 | 37.9 | 30.4 | 6014Z | ZZ | 2RS | 6000 | 3600 | 7000 | 0.586 |
| 70.0 | 125.0 | 24.0 | 1.50 | 60.8 | 46.5 | 6214Z | ZZ | 2RS | 4800 | 3400 | 5800 | 1.100 |
| 70.0 | 150.0 | 35.0 | 2.10 | 104.0 | 68.0 | 6314Z | ZZ | 2RS | 4500 | 3000 | 5300 | 2.550 |
| 75.0 | 95.0 | 10.0 | 0.60 | 11.3 | 11.9 | 6815Z | ZZ | 2RS | 6300 | 4000 | 7500 | 0.143 |
| 75.0 | 105.0 | 16.0 | 1.00 | 23.4 | 22.5 | 6915Z | ZZ | 2RS | 6000 | 3600 | 7000 | 0.365 |
| 75.0 | 115.0 | 20.0 | 1.10 | 40.3 | 33.2 | 6015Z | ZZ | 2RS | 5600 | 3400 | 6700 | 0.625 |
| 75.0 | 130.0 | 25.0 | 1.50 | 60.8 | 45.4 | 6215Z | ZZ | 2RS | 4800 | 3200 | 5600 | 1.200 |
| 75.0 | 160.0 | 37.0 | 2.10 | 113.0 | 77.0 | 6315Z | ZZ | 2RS | 4300 | 2800 | 5000 | 3.050 |
| 80.0 | 100.0 | 10.0 | 0.60 | 11.6 | 12.7 | 6816Z | ZZ | 2RS | 6000 | 3600 | 7000 | 0.152 |
| 80.0 | 110.0 | 16.0 | 1.00 | 25.0 | 23.9 | 6916Z | ZZ | 2RS | 5600 | 3400 | 6700 | 0.385 |
| 80.0 | 125.0 | 22.0 | 1.10 | 42.4 | 35.6 | 6016Z | ZZ | 2RS | 5300 | 3200 | 6300 | 0.872 |
| 80.0 | 140.0 | 26.0 | 2.00 | 71.5 | 53.5 | 6216Z | ZZ | 2RS | 4500 | 3000 | 5300 | 1.450 |
| 80.0 | 170.0 | 39.0 | 2.10 | 123.0 | 86.5 | 6316Z | ZZ | 2RS | 3900 | 2600 | 4700 | 3.640 |
| 85.0 | 110.0 | 13.0 | 1.00 | 16.0 | 16.8 | 6817Z | ZZ | 2RS | 5300 | 3400 | 6300 | 0.268 |
| 85.0 | 120.0 | 18.0 | 1.10 | 31.9 | 29.5 | 6917Z | ZZ | 2RS | 5300 | 3000 | 6300 | 0.525 |
| 85.0 | 130.0 | 22.0 | 1.10 | 50.3 | 41.2 | 6017Z | ZZ | 2RS | 4800 | 3000 | 5600 | 0.835 |
| 85.0 | 150.0 | 28.0 | 2.00 | 83.2 | 64.0 | 6217Z | ZZ | 2RS | 4200 | 2800 | 4800 | 1.950 |
| 85.0 | 180.0 | 41.0 | 3.00 | 133.0 | 96.5 | 6317Z | ZZ | 2RS | 3700 | 2400 | 4400 | 4.350 |
| 90.0 | 115.0 | 13.0 | 1.00 | 16.5 | 18.0 | 6818Z | ZZ | 2RS | 5300 | 3200 | 6300 | 0.282 |
| 90.0 | 125.0 | 18.0 | 1.10 | 32.8 | 31.5 | 6918Z | ZZ | 2RS | 5000 | 2900 | 6000 | 0.600 |
| 90.0 | 140.0 | 24.0 | 1.50 | 52.3 | 45.1 | 6018Z | ZZ | 2RS | 4700 | 2800 | 5600 | 1.160 |
| 90.0 | 160.0 | 30.0 | 2.00 | 96.1 | 71.5 | 6218Z | ZZ | 2RS | 3800 | 2600 | 4500 | 2.180 |
| 90.0 | 190.0 | 43.0 | 3.00 | 144.0 | 109.0 | 6318Z | ZZ | 2RS | 3400 | 2400 | 4000 | 5.000 |
| 95.0 | 120.0 | 13.0 | 1.00 | 18.6 | 19.8 | 6819Z | ZZ | 2RS | 5000 | 3000 | 6000 | 0.295 |
| 95.0 | 130.0 | 18.0 | 1.10 | 33.7 | 33.5 | 6919Z | ZZ | 2RS | 4800 | 2800 | 5600 | 0.588 |
| 95.0 | 145.0 | 24.0 | 1.50 | 79.0 | 55.0 | 6019Z | ZZ | 2RS | 4200 | 2800 | 4800 | 1.190 |
| 95.0 | 170.0 | 32.0 | 2.10 | 109.0 | 79.1 | 6219Z | ZZ | 2RS | 3600 | 2400 | 4300 | 2.640 |
| 95.0 | 200.0 | 45.0 | 3.00 | 153.0 | 118.0 | 6319Z | ZZ | 2RS | 3200 | 2300 | 3800 | 5.780 |
| 100.0 | 125.0 | 13.0 | 1.00 | 16.9 | 19.1 | 6820Z | ZZ | 2RS | 4800 | 3000 | 5600 | 0.310 |
| 100.0 | 140.0 | 20.0 | 1.10 | 44.5 | 42.0 | 6920Z | ZZ | 2RS | 4500 | 2600 | 5300 | 0.786 |
| 100.0 | 150.0 | 24.0 | 1.10 | 63.7 | 50.4 | 6020Z | ZZ | 2RS | 4300 | 2600 | 5000 | 1.220 |
| 100.0 | 180.0 | 34.0 | 2.10 | 123.0 | 94.0 | 6220Z | ZZ | 2RS | 3400 | 2400 | 4000 | 3.150 |
| 100.0 | 215.0 | 47.0 | 3.00 | 173.0 | 140.0 | 6320Z | ZZ | 2RS | 3000 | 2200 | 3600 | 7.110 |
| 105.0 | 130.0 | 13.0 | 1.00 | 17.4 | 20.4 | 6821Z | ZZ | 2RS | 4500 | 2800 | 5300 | 0.323 |
| 105.0 | 145.0 | 20.0 | 1.10 | 46.3 | 44.8 | 6921Z | ZZ | 2RS | 4300 | 2500 | 5000 | 0.805 |
| 105.0 | 160.0 | 26.0 | 2.00 | 69.8 | 61.2 | 6021Z | ZZ | 2RS | 4000 | 2400 | 4800 | 1.560 |
| 105.0 | 190.0 | 36.0 | 2.10 | 133.0 | 4.0 | 6221Z | ZZ | 2RS | 3200 | 2200 | 3800 | 3.820 |
| 105.0 | 225.0 | 49.0 | 3.00 | 182.0 | 153.0 | 6321Z | ZZ | 2RS | 2800 | 2100 | 3400 | 8.250 |
| 110.0 | 140.0 | 16.0 | 1.00 | 24.3 | 27.2 | 6822Z | ZZ | 2RS | 4300 | 2600 | 5000 | 0.500 |
| 110.0 | 150.0 | 20.0 | 1.10 | 47.6 | 47.5 | 6922Z | ZZ | 2RS | 4000 | 2400 | 4800 | 0.840 |
| 110.0 | 170.0 | 28.0 | 2.00 | 75.1 | 67.3 | 6022Z | ZZ | 2RS | 3800 | 2400 | 4500 | 1.960 |
| 110.0 | 200.0 | 38.0 | 2.10 | 144.0 | 117.0 | 6222Z | ZZ | 2RS | 3000 | 2000 | 3600 | 4.450 |
| 110.0 | 240.0 | 50.0 | 3.00 | 203.0 | 180.0 | 6322Z | ZZ | 2RS | 2600 | 1900 | 3200 | 9.550 |
| 120.0 | 150.0 | 16.0 | 1.00 | 25.0 | 26.0 | 6824Z | ZZ | 2RS | 3800 | 2400 | 4500 | 0.540 |
| 120.0 | 180.0 | 28.0 | 2.00 | 86.0 | 79.7 | 6024Z | ZZ | 2RS | 3400 | 2200 | 4000 | 2.050 |
| 120.0 | 215.0 | 40.0 | 2.10 | 154.0 | 131.0 | 6224Z | ZZ | 2RS | 2800 | 1900 | 3400 | 5.300 |
| 130.0 | 165.0 | 18.0 | 1.10 | 32.5 | 34.0 | 6826Z | ZZ | 2RS | 3600 | 2200 | 4300 | 0.774 |
| 130.0 | 200.0 | 33.0 | 2.00 | 102.0 | 93.9 | 6026Z | ZZ | 2RS | 3200 | 2000 | 3800 | 3.160 |
| 130.0 | 230.0 | 40.0 | 3.00 | 166.0 | 148.0 | 6226Z | ZZ | 2RS | 2600 | 1700 | 3200 | 6.140 |
| 140.0 | 175.0 | 18.0 | 1.10 | 34.0 | 36.5 | 6828Z | ZZ | 2RS | 3400 | 2000 | 4000 | 0.828 |
| 140.0 | 210.0 | 33.0 | 2.00 | 110.6 | 109.0 | 6928Z | ZZ | 2RS | 3000 | 1800 | 3600 | 3.250 |
| 150.0 | 225.0 | 35.0 | 2.10 | 125.0 | 124.0 | 6030Z | ZZ | 2RS | 2600 | 1700 | 3200 | 4.800 |
| 160.0 | 240.0 | 38.0 | 2.10 | 138.0 | 137.0 | 6032Z | ZZ | 2RS | 2400 | 1600 | 3000 | 5.900 |
深溝ボールベアリング（N溝付き）
| 主要寸法 | 基本定格荷重（kN） | 呼び番号 | 許容回転速度 | 参考質量 | ||||||||
| d | D | B | r（最小） | r1（最小） | Cr | C0r | N | NR | ZNR | GR潤滑 | 油潤滑 | |
| 10.0 | 22.0 | 6.0 | 0.3 | 0.3 | 1.95 | 0.75 | 6900N | NR | ZNR | 32000.000 | 40000 | 0.01 |
| 10.0 | 30.0 | 9.0 | 0.6 | 0,5 | 5,10 | 2.39 | 6200Ｎ | NR | ZNR | 24000.000 | 30000 | 0.032 |
| 10.0 | 35.0 | 11.0 | 0.6 | 0.5 | 7.66 | 3.45 | 63０0Ｎ | NR | ZNR | 20000.000 | 25000 | 0.055 |
| 12.0 | 23.0 | 6.0 | 0.3 | 0.3 | 2.25 | 0.98 | 6901Ｎ | NR | ZNR | 30000.000 | 36000 | 0.011 |
| 12.0 | 28.0 | 8.0 | 0.3 | 0.3 | 5.10 | 2.37 | 6001Ｎ | NR | ZNR | 27000.000 | 32000 | 0.022 |
| 12.0 | 32.0 | 10.0 | 0.6 | 0.5 | 6.75 | 3.05 | 6201Ｎ | NR | ZNR | 22000.000 | 28000 | 0.037 |
| 12.0 | 37.0 | 12.0 | 1.0 | 0.5 | 8.58 | 3.92 | 6301Ｎ | NR | ZNR | 19000.000 | 23000 | 0.063 |
| 15.0 | 23.0 | 7.0 | 0.3 | 0.3 | 4.33 | 2.25 | 6902N | NR | ZNR | 24000.000 | 29000 | 0.015 |
| 15.0 | 32.0 | 9.0 | 0.3 | 0.3 | 5.62 | 2.82 | 6002Ｎ | NR | ZNR | 22000.000 | 27000 | 0.031 |
| 15.0 | 35.0 | 11.0 | 0.6 | 0.5 | 7.64 | 3.72 | 6202Ｎ | NR | ZNR | 19000.000 | 24000 | 0.045 |
| 15.0 | 42.0 | 13.0 | 1.0 | 0.5 | 11.40 | 5.40 | 6302Ｎ | NR | ZNR | 17000.000 | 20000 | 0.083 |
| 17.0 | 30.0 | 7.0 | 0.3 | 0.3 | 4.60 | 2.55 | 6903Ｎ | NR | ZNR | 22000.000 | 28000 | 0.018 |
| 17.0 | 35.0 | 10.0 | 0.3 | 0.3 | 6.30 | 3.25 | 6003Ｎ | NR | ZNR | 19000.000 | 24000 | 0.039 |
| 17.0 | 40.0 | 12.0 | 0.6 | 0.5 | 9.80 | 4.75 | 6203Ｎ | NR | ZNR | 17000.000 | 20000 | 0.065 |
| 17.0 | 47.0 | 14.0 | 1.0 | 0.5 | 13.50 | 6.55 | 6303N | NR | ZNR | 15000.000 | 19000 | 0.116 |
| 17.0 | 62.0 | 17.0 | 1.1 | 0.5 | 21.80 | 9.85 | 6403Ｎ | NR | ZNR | 12000.000 | 15000 | 0.27 |
| 2.0 | 32.0 | 7.0 | 0.3 | 0,3 | 3,48 | 2.23 | 6804Ｎ | NR | ZNR | 19000.000 | 24000 | 0.018 |
| 2.0 | 37.0 | 9.0 | 0.3 | 0.3 | 6.38 | 3.65 | 6904Ｎ | NR | ZNR | 18000.000 | 22000 | 0.037 |
| 2.0 | 42.0 | 12.0 | 0.6 | 0.5 | 9.44 | 5.{}3 | 6004Ｎ | NR | ZNR | 17000.000 | 20000 | 0.07 |
| 2.0 | 47.0 | 14.0 | 1.0 | 0.5 | 12.85 | 6.60 | 6204Ｎ | NR | ZNR | 15000.000 | 18000 | 0.103 |
| 2.0 | 52.0 | 15.0 | 1.1 | 0.5 | 16.00 | 7.88 | 6304Ｎ | NR | ZNR | 13000.000 | 16000 | 0.146 |
| 2.0 | 72.0 | 19.0 | 1.1 | 0.5 | 31.10 | 5.20 | 6404Ｎ | NR | ZNR | 10000.000 | 13000 | 0.4 |
| 22.0 | 44.0 | 12.0 | 0.6 | 0.5 | 9.40 | 5.05 | 60/22Ｎ | NR | ZNR | 17000.000 | 20000 | 0.074 |
| 22.0 | 50.0 | 14.0 | 1.0 | 0.5 | 12.90 | 6.80 | 62/22Ｎ | NR | ZNR | 14000.000 | 16000 | 0.117 |
| 22.0 | 56.0 | 16.0 | 1.1 | 0.5 | 18.50 | 9.25 | 63/22Ｎ | NR | ZNR | 13000.000 | 16000 | 0.177 |
| 25.0 | 37.0 | 7.0 | 0.3 | 0.3 | 3.84 | 2.80 | 6805Ｎ | NR | ZNR | 17000.000 | 20000 | 0.022 |
| 25.0 | 42.0 | 9.0 | 0.3 | 0.3 | 7.32 | 4.56 | 6905Ｎ | NR | ZNR | 16000.000 | 19000 | 0.043 |
| 25.0 | 47.0 | 12.0 | 0.6 | 0.5 | 10.10 | 5.85 | 6005Ｎ | NR | ZNR | 15000.000 | 18000 | 0.08 |
| 25.0 | 52.0 | 15.0 | 1.0 | 0.5 | 14.00 | 7.87 | 6205N | NR | ZNR | 12000.000 | 15000 | 0.128 |
| 25.0 | 62.0 | 17.0 | 1.1 | 0,5 | 22.50 | 11.50 | 6305Ｎ | NR | ZNR | 11000.000 | 13000 | 0.227 |
| 25.0 | 80.0 | 21.0 | 1.5 | 0.5 | 36.00 | 18.50 | 6405Ｎ | NR | ZNR | 9000.000 | 11000 | 0.532 |
| 28.0 | 52.0 | 12.0 | 0.6 | 0.5 | 10.70 | 6.63 | 60/28Ｎ | NR | ZNR | 14000.000 | 16000 | O､101 |
| 28.0 | 58.0 | 16.0 | 1.0 | 0.5 | 16.60 | 9.54 | 62/28Ｎ | NR | ZNR | 12000.000 | 14000 | 0.174 |
| 28.0 | 68.0 | 18.0 | 1.1 | 0.5 | 23.50 | 12.10 | 63/28Ｎ | NR | ZNR | 10000.000 | 12500 | 0.292 |
| 30.0 | 42.0 | 7.0 | 0.3 | 0.5 | 4.15 | 3.32 | 6806N | NR | ZNR | 15000.000 | 18000 | 0.025 |
| 30.0 | 47.0 | 9.0 | 0.3 | 0.5 | 7.25 | 5.05 | 6906N | NR | ZNR | 14000.000 | 17000 | 0.049 |
| 30.0 | 55.0 | 13.0 | 1.0 | 0.5 | 13.20 | 8.30 | 6006N | NR | ZNR | 12000.000 | 15000 | 0.117 |
| 30.0 | 62.0 | 16.0 | 1.0 | 0.5 | 19.50 | 11.30 | 6206Ｎ | NR | ZNR | 10000.000 | 13000 | 0.203 |
| 30.0 | 72.0 | 19.0 | 1.1 | 0.5 | 26.70 | 14.90 | 6306Ｎ | NR | ZNR | 9000.000 | 11000 | 0.355 |
| 30.0 | 90.0 | 23.0 | 1.5 | 0.5 | 43.50 | 24.50 | 6406Ｎ | NR | ZNR | 8100.000 | 10000 | 0.731 |
| 32.0 | 58.0 | 13.0 | 1.0 | 0,5 | 13.30 | 8.40 | 60/32Ｎ | NR | ZNR | 12000.000 | 14000 | 0.129 |
| 32.0 | 65.0 | 17.0 | 1.0 | 0.5 | 21.20 | 12.50 | 62/32Ｎ | NR | ZNR | 10000.000 | 12000 | 0.231 |
| 32.0 | 75.0 | 20.0 | 1.1 | 0.5 | 29.90 | 16.20 | 63/32Ｎ | NR | ZNR | 9000.000 | 10000 | 0.392 |
| 35.0 | 47.0 | 7.0 | 0.3 | 0.5 | 4.29 | 3.60 | 6807Ｎ | NR | ZNR | 13000.000 | 16000 | 0.029 |
| 35.0 | 55.0 | 10.0 | 0.6 | 0.5 | 9.54 | 6.83 | 6907Ｎ | NR | ZNR | 11000.000 | 14000 | 0.078 |
| 35.0 | 62.0 | 14.0 | 1.0 | 0.5 | 16.00 | 10.30 | 6007Ｎ | NR | ZNR | 10000.000 | 13000 | 0.152 |
| 35.0 | 72.0 | 17.0 | 1.1 | 0.5 | 25.60 | 15.50 | 6207Ｎ | NR | ZNR | 9000.000 | 11000 | 0.285 |
| 35.0 | 80.0 | 21.0 | 1.5 | 0.5 | 33.40 | 19.20 | 6307Ｎ | NR | ZNR | 8500.000 | 10000 | 0.455 |
| 35.0 | 100.0 | 25.0 | 1.5 | 0.5 | 55.30 | 31.00 | 6407Ｎ | NR | ZNR | 7000.000 | 8500 | 0.925 |
| 40.0 | 52.0 | 7.0 | 0.3 | O､3 | 4.52 | 4.10 | 6808Ｎ | NR | ZNR | 11000.000 | 14000 | 0.033 |
| 40.0 | 62.0 | 12.0 | 0.6 | 0.5 | 12.20 | 8.90 | 6908Ｎ | NR | ZNR | 10000.000 | 13000 | 0.115 |
| 40.0 | 68.0 | 15.0 | 1.0 | 0.5 | 16.60 | 11.90 | 6008Ｎ | NR | ZNR | 9500.000 | 12000 | 0.189 |
| 40.0 | 80.0 | 18.0 | 1.1 | 0.5 | 27.60 | 17.40 | 6208Ｎ | NR | ZNR | 8200.000 | 10000 | 0.373 |
| 40.0 | 90.0 | 23.0 | 1.5 | 0.5 | 40.00 | 24.()0 | 6308N | NR | ZNR | 7500.000 | 9000 | 0.641 |
| 40.0 | 110] | 27.0 | 2.0 | 0.5 | 63.60 | 36.60 | 6408Ｎ | NR | ZNR | 6700.000 | 8000 | 1.24 |
| 45.0 | 58.0 | 7.0 | 0.3 | 0.3 | 4.73 | 4.50 | 6809Ｎ | NR | ZNR | 9500.000 | 12000 | 0.041 |
| 45.0 | 68.0 | 12.0 | 0.6 | 0.5 | 14.00 | 10.90 | 6909N | NR | ZNR | 9000.000 | 1000 | 0.131 |
| 45.0 | 75.0 | 16.0 | 1.0 | 0,5 | 19.90 | 14.()0 | 6009N | NR | ZNR | 9000.000 | 1000 | 0.242 |
| 45.0 | 85.0 | 19.0 | 1.1 | 0.5 | 31.20 | 20.60 | 6209Ｎ | NR | ZNR | 7500.000 | 9000 | 0.42 |
| 45.0 | 100.0 | 25.0 | 1.5 | 0.5 | 48.90 | 29.30 | 6309Ｎ | NR | ZNR | 6700.000 | 8000 | 0.853 |
| 45.0 | 120.0 | 29.0 | 2.0 | 0.5 | 72.90 | 42.60 | 6409N | NR | ZNR | 6000.000 | 7000 | 1.56 |
| 50.0 | 65.0 | 7.0 | 0.3 | 0.3 | 4.93 | 4.94 | 6810N | NR | ZNR | 9000.000 | 1000 | 0.057 |
| 50.0 | 72.0 | 12.0 | 0.6 | 0.5 | 14.40 | 11.70 | 6910N | NR | ZNR | 8500.000 | 0 | 0.139 |
| 50.0 | 80.0 | 16.0 | 1.0 | 0.5 | 20.70 | 15.40 | 6010N | NR | ZNR | 7500.000 | 9500 | 0.262 |
| 50.0 | 90.0 | 20.0 | 1.1 | 0.5 | 35.10 | 23.20 | 6210N | NR | ZNR | 7000.000 | 8500 | 0.467 |
| 50.0 | 110.0 | 27.0 | 2.0 | 0.5 | 57.60 | 35.30 | 6310N | NR | ZNR | 6300.000 | 7500 | 1.1 |
| 50.0 | 130.0 | 31.0 | 2.1 | 0.5 | 82.50 | 49.30 | 6410N | NR | ZNR | 5300.000 | 6300 | 1.92 |
| 55.0 | 72.0 | 9.0 | 0.3 | 0.3 | 9､10 | 8.45 | 6811N | NR | ZNR | 8500.000 | 0 | 0.081 |
| 55.0 | 80.0 | 13.0 | 1.0 | 0.5 | 18.90 | 15.1D | 6911N | NR | ZNR | 8000.000 | 9500 | 0.18 |
| 55.0 | 90.0 | 18.0 | 1.1 | 0.5 | 26.70 | 20.10 | 6011N | NR | ZNR | 7500.000 | 9000 | 0.382 |
| 55.0 | 100.0 | 21.0 | 1.5 | 0.5 | 43.40 | 29.20 | 6211N | NR | ZNR | 6300.000 | 7500 | 0.609 |
| 55.0 | 120.0 | 29.0 | 2.0 | 0.5 | 71.60 | 44.80 | 6311N | NR | ZNR | 5600.000 | 6700 | 1.35 |
| 55.0 | 140.0 | 33.0 | 2.1 | 0.5 | 98.00 | 62.30 | 6411N | NR | ZNR | 5000.000 | 6000 | 2.3 |
| 60.0 | 78.0 | 10.0 | 0.3 | 0.3 | 10.30 | 10.01 | 6812N | NR | ZNR | 7500.000 | 9000 | 0.101 |
| 60.0 | 85.0 | 13.0 | 1.0 | 0.5 | 19.40 | 16.20 | 6912N | NR | ZNR | 乃00 | 9000 | 0.193 |
| 60.0 | 95.0 | 18.0 | 1.1 | 0.5 | 30.20 | 23.00 | 6012N | NR | ZNR | 6700.000 | 8000 | 0.399 |
| 60.0 | 110.0 | 22.0 | 1.5 | 0.5 | 47.80 | 32.90 | 6212N | NR | ZNR | 5800.000 | 7000 | 0.804 |
| 60.0 | 130.0 | 31.0 | 2.1 | 0.5 | 81.90 | 51.80 | 6312Ｎ | NR | ZNR | 5100.000 | 6000 | 1.71 |
| 60.0 | 150.0 | 35.0 | 2.1 | 0.5 | 109.00 | 70.05 | 6412N | NR | ZNR | 4800.000 | 5600 | 2.98 |
| 65.0 | 85.0 | 10.0 | 0.6 | 0.5 | 10.80 | 10.70 | 6813N | NR | ZNR | 7000.000 | 8400 | 0.127 |
| 65.0 | 90.0 | 13.0 | 1.0 | 0,5 | 19.90 | 17.50 | 6913N | NR | ZNR | 6700.000 | 8000 | 0.206 |
| 65.0 | 100.0 | 18.0 | 1.1 | 0,5 | 30.80 | 24.90 | 6013N | NR | ZNR | 6300.000 | 7500 | 0.42 |
| 65.0 | 120.0 | 23.0 | 1.5 | 0.5 | 50.70 | 37.10 | 6213N | NR | ZNR | 5300.000 | 6300 | 1.04 |
| 65.0 | 140.0 | 33.0 | 2.1 | 0.5 | 92.50 | 59.60 | 6313N | NR | ZNR | 4800.000 | 5600 | 2.15 |
| 65.0 | 160.0 | 37.0 | 2.1 | 0.5 | 118.00 | 78.50 | 6413N | NR | ZNR | 4500.000 | 5300 | 3.36 |
| 70.0 | 90.0 | 10.0 | 0.6 | 0.5 | 11.20 | 11.70 | 6814N | NR | ZNR | 6700.000 | 8000 | 0.135 |
| 70.0 | 100.0 | 16.0 | 1.0 | 0.5 | 23.70 | 21.10 | 6914N | NR | ZNR | 6300.000 | 7500 | 0.342 |
| 70.0 | 110.0 | 20.0 | 1.1 | 0.5 | 37,90 | 30.4D | 6014N | NR | ZNR | 6000.000 | 7000 | 0.586 |
| 70.0 | 125.0 | 24.0 | 1.5 | 0.5 | 55.80 | 41.10 | 6214N | NR | ZNR | 5000.000 | 6000 | 1.12 |
| 70.0 | 150.0 | 35.0 | 2.1 | 0.5 | 104.00 | 68.00 | 6314N | NR | ZNR | 4500.000 | 5300 | 2.55 |
| 70.0 | 180.0 | 42.0 | 3.0 | 0.5 | 135.00 | 95.50 | 6414N | NR | ZNR | 3800.000 | 4500 | 4.95 |
| 75.0 | 95.0 | 10.0 | 0.6 | 0.5 | 11.30 | 11.90 | 6815N | NR | ZNR | 6300.000 | 7500 | 0.143 |
| 75.0 | 105.0 | 16.0 | 1.0 | 0.5 | 23.40 | 22.50 | 6915N | NR | ZNR | 6000.000 | 7000 | 0.365 |
| 75.0 | 115.0 | 20.0 | 1.1 | 0.5 | 40.30 | 33.20 | 6015N | NR | ZNR | 5600.000 | 6700 | 0.625 |
| 75.0 | 130.0 | 25.0 | 1.5 | 0.5 | 60.80 | 45.40 | 6215N | NR | ZNR | 4800.000 | 5600 | 1.2 |
| 75.0 | 160.0 | 37.0 | 2.1 | 0.5 | H3.00 | 77.00 | 6315N | NR | ZNR | 4300.000 | 5000 | 3.05 |
| 75.0 | 190.0 | 45.0 | 3.0 | 0.5 | 153.00 | 14.0D | 6415N | NR | ZNR | 3600.000 | 4300 | 6.8 |
| 80.0 | 100.0 | 10.0 | 0.6 | 0.5 | 11.60 | 12.70 | 6816N | NR | ZNR | 6000.000 | 7000 | 0.152 |
| 80.0 | 110.0 | 16.0 | 1.0 | 0､5 | 25.00 | 23.90 | 6916N | NR | ZNR | 5600.000 | 6700 | 0.385 |
| 80.0 | 125.0 | 22.0 | 1.1 | 0.5 | 42.40 | 35.60 | 6016N | NR | ZNR | 5300.000 | 6300 | 0.872 |
| 80.0 | 140.0 | 26.0 | 2.0 | 0,5 | 71.50 | 53.5D | 6216N | NR | ZNR | 4500.000 | 5300 | 1.45 |
| 80.0 | 170.0 | 39.0 | 2.1 | 0.5 | 123.00 | 86.50 | 6316N | NR | ZNR | 3900.000 | 4200 | 3.64 |
| 80.0 | 200.0 | 48.0 | 3.0 | 0.5 | 163.00 | 25.00 | 6416N | NR | ZNR | 3400.000 | 4000 | 8.05 |
| 85.0 | 110.0 | 13.0 | 1.0 | 0.5 | 16.00 | 16.80 | 6817N | NR | ZNR | 5300.000 | 6300 | 0.268 |
| 85.0 | 120.0 | 18.0 | 1.1 | 0.5 | 31.90 | 29.50 | 6917N | NR | ZNR | 5300.000 | 6300 | 0.525 |
| 85.0 | 130.0 | 22.0 | 1.1 | 0.5 | 47.30 | 40.10 | 6017N | NR | ZNR | 5000.000 | 6000 | 0.885 |
| 85.0 | 150.0 | 18.0 | 2.0 | 0.5 | 77.20 | 59.30 | 6217N | NR | ZNR | 4300.000 | 5000 | 1.85 |
| 85.0 | 180.0 | 41.0 | 3.0 | 0.5 | 133.00 | 96.60 | 6317Ｎ | NR | ZNR | 3700.000 | 4400 | 4.35 |
| 90.0 | 115.0 | 13.0 | 1.0 | 0.5 | 16.50 | 18.00 | 6818N | NR | ZNR | 5300.000 | 6300 | 0.282 |
| 90.0 | 125.0 | 18.0 | 1.1 | 0.5 | 32.80 | 31.50 | 6918N | NR | ZNR | 5000.000 | 6000 | 0.6 |
| 90.0 | 140.0 | 24.0 | 1.5 | 0.5 | 52.30 | 45.10 | 6018N | NR | ZNR | 4700.000 | 5600 | 1.16 |
| 90.0 | 160.0 | 30.0 | 2.0 | 0.5 | 96.10 | 71.50 | 6218N | NR | ZNR | 3800.000 | 4500 | 2.18 |
| 90.0 | 190.0 | 43.0 | 3.0 | 0.5 | 143.00 | 7.00 | 6318N | NR | ZNR | 3400.000 | 4000 | 5 |
| 95.0 | 120.0 | 13.0 | 1.0 | 0.5 | 18.60 | 19.80 | 6819N | NR | ZNR | 5000.000 | 6000 | 0.295 |
| 90.0 | 130.0 | 18.0 | 1.1 | 0.5 | 33.70 | 33.50 | 6919N | NR | ZNR | 4800.000 | 5600 | 0.588 |
| 90.0 | 145.0 | 24.0 | 1.5 | 0.5 | 58.00 | 50.10 | 6019N | NR | ZNR | 4500.000 | 5300 | 1.18 |
| 90.0 | 170.0 | 32.0 | 2.1 | 0.5 | 109.00 | 81.50 | 6219N | NR | ZNR | 3600.000 | 4300 | 2.64 |
| 90.0 | 200.0 | 45.0 | 3.0 | 0.5 | 153.00 | 18.00 | 6319N | NR | ZNR | 3200.000 | 3800 | 5.78 |
| 100.0 | 125.0 | 13.0 | 1.0 | 0.5 | 16.90 | 19.1 | 6820N | NR | ZNR | 4800.000 | 5600 | 0.31 |
| 100.0 | 140.0 | 20.0 | 1.1 | 0.5 | 44.50 | 42.0 | 6920N | NR | ZNR | 4500.000 | 5300 | 0.786 |
| 100.0 | 150.0 | 24.0 | 1.5 | 0.5 | 63.70 | 50.4 | 6020N | NR | ZNR | 4300.000 | 5000 | 1.22 |
| 100.0 | 180.0 | 34.0 | 2.1 | 0.5 | 122.00 | 92.7 | 6220N | NR | ZNR | 3400.000 | 4000 | 3.15 |
| 105.0 | 130.0 | 13.0 | 1.0 | 0.5 | 17.40 | 20.4 | 6821N | NR | ZNR | 4500.000 | 5300 | 0.323 |
| 105.0 | 145.0 | 20.0 | 1.1 | 0.5 | 46.30 | 44.8 | 6921N | NR | ZNR | 4300.000 | 5000 | 0.805 |
| 105.0 | 160.0 | 26.0 | 2.0 | 0.5 | 69.80 | 61.2D | 6021N | NR | ZNR | 4000.000 | 4800 | 1.56 |
| 105.0 | 190.0 | 36.0 | 2.1 | 0.5 | 133.00 | 4.0 | 6221N | NR | ZNR | 3200.000 | 3800 | 3.82 |
| 110.0 | 140.0 | 16.0 | 1.0 | 0.5 | 24.30 | 27.2 | 6822N | NR | ZNR | 4300.000 | 5000 | 0.5 |
| 110.0 | 150.0 | 20.0 | 1.1 | 0.5 | 47.60 | 47.5 | 6922N | NR | ZNR | 4000.000 | 4800 | 0.84 |
| 110.0 | 170.0 | 28.0 | 2.0 | 0,5 | 75.10 | 67.3 | 6022N | NR | ZNR | 3800.000 | 4500 | 1.96 |
| 110.0 | 200.0 | 38.0 | 2.1 | 0.5 | 144.00 | 17.0 | 6222N | NR | ZNR | 3000.000 | 3600 | 4.45 |
| 120.0 | 150.0 | 16.0 | 1.0 | 0.5 | 25,00 | 26.0 | 6824N | NR | ZNR | 3800.000 | 4500 | 0.54 |
| 12.0 | 165.0 | 22.0 | 1.1 | 0.5 | 57.20 | 56.9 | 6924N | NR | ZNR | 3600.000 | 4300 | 1.15 |
| 12.0 | 180.0 | 28.0 | 2.0 | 0.5 | 86.00 | 79.7 | 6024N | NR | ZNR | 3400.000 | 4000 | 2.05 |
| 130.0 | 165.0 | 18.0 | 1.1 | 0.5 | 32.50 | 34.0 | 6826Ｎ | NR | ZNR | 3600.000 | 4300 | 0.774 |
| 130.0 | 180.0 | 24.0 | 1.5 | 0.5 | 69.50 | 70.0 | 6926N | NR | ZNR | 3400.000 | 4000 | 1.92 |
| 130.0 | 200.0 | 33.0 | 2.0 | 0.5 | 102.00 | 94.0 | 6026N | NR | ZNR | 3200.000 | 3800 | 3.16 |
| 140.0 | 175.0 | 18.0 | 1.1 | 0,5 | 34.00 | 36.5 | 6828N | NR | ZNR | 3400.000 | 4000 | 0.828 |
| 140.0 | 190.0 | 24.0 | 1.5 | 0.5 | 71.20 | 74.6 | 6928N | NR | ZNR | 3200.000 | 3800 | 1.6 |
| 150.0 | 190.0 | 20.0 | 1.1 | 0.5 | 42.50 | 44.0 | 6830N | NR | ZNR | 3000.000 | 3600 | 1.12 |
| 160.0 | 200.0 | 20.0 | 1.1 | 0.5 | 44.00 | 48.0 | 6832N | NR | ZNR | 2800.000 | 3400 | 1.19 |
